Specifications
| Parameter | |||||
| Mode | H5110A | ||||
| Nominal Voltage | 51.2V | ||||
| Nominal Capacity | 10KWH(195AH) | ||||
| Battery Impedance | ≤15mΩ | ||||
| Shipment Voltage | 51.2~54.4V | ||||
| Limit Charging Voltage | 58.40V | ||||
| Maximum Charging Current | Ambient Temperature | Relative Humidity | Charging Current | Limit Charging Voltage | Cutoff Current for CV |
| 0°C~15°C | 65±20% | MAX：0.2C | MAX：58.4V | 0.025C | |
| 15°C~45°C | 65±20% | MAX：0.5C | MAX：58.4V | 0.025C | |
| Recommended Charging Current | 0.2C:40A | ||||
| Recommended Discharge Current | 0.5C:100A | ||||
| Maximum Discharge Current | 100A(-20°C~60°C;65±20%RH) | ||||
| Service Life | 0.2C charge/discharge, 5000 times ≥80% initial capacity | ||||
| Cooling Method | Self-cooling | ||||
| Communication | RS485 RS232 CAN | ||||
| Battery Warranty | 3-5 years | ||||
| Operating Temperature | –20~60℃ | ||||
| Storage Environment | -20°C~45°C | ||||
| Humidity | 65±20%RH | ||||
| Weight | ≈80 kg | ||||
| Packaging | 30mm Honeycomb Carton: 780*625*270mm | ||||
| Dimension | 700*545*188mm | ||||
